Home » Products » Sealing Machine » Automatic Cap Sealing Machine

Automatic Cap Sealing Machine

Automatic Cap Sealing Machine
Automatic Cap Sealing Machine
Product Code : CPACS
Product Description

Owing to our years of experience and experienced professionals, we are able to manufacture, export and supply a wide range of Automatic Cap Sealing Machine. The offered machine is manufactured by our dexterous team of professionals using quality tested components and contemporary technology. It is mainly used for cap sealing of different kinds of bottles in pharmaceutical, food processing, beverage, and other related segments. Further, this Automatic Cap Sealing Machine is available in various specifications at market leading price.

Features:

  • High efficiency

  • Durable finish standards

  • Longer service life

  • Corrosion resistance

TECHNICAL SPECIFICATIONS

MODEL NO.





CPACS-1 S





CPACS-4 S





CPACS-6 S





Direction





Left To Right.





Left To Right.





Left To Right.





Production Rate OF 100 ml containers





Up to 30 To 60 Bottles / Min





Up to 60 To 80 Bottles / Min





Up to 80 To 120 Bottles / Min





Electrical Supply





1.00 HP For

Main Drive





1.5 HP For

Main Drive





2.00 HP For

Main Drive





No of Sealing Head





Single





Four





Six





Power Requirement





440 Volts, 3 Phase (4 wire System) 50 Hz.





440 Volts, 3 Phase (4 wire System) 50 Hz.





440 Volts, 3 Phase (4 wire System) 50 Hz.





Height of Conveyor





Adjustable from 800 To 850 MM





Adjustable from 800 To 850 MM





Adjustable from 800 To 850 MM





Conveyor Width X Length





(Bigger width for larger size jars also available)





90mm  x 6 Ft.





90 mm X 6 Ft.





90 mm X 8 Ft.





Bottle Diameter





22 MM To 100 MM MAX. Adjustable as per client requirement





22 MM To 100 MM MAX. Adjustable as per client requirement





22 MM To 100 MM MAX. Adjustable as per client requirement





Height





55 MM To 210 MM MAX. Adjustable as per client requirement





55 MM To 210 MM MAX. Adjustable as per client requirement





55 MM To 210 MM MAX. Adjustable as per client requirement





Screw cap





18 - 58 MM DIAMETER.(with help of change parts)





18 - 58 MM DIAMETER.(with help of change parts)





18 - 58 MM DIAMETER.(with help of change parts)






NOTE:  Portable smaller range and large dia meter container size capping, 2 in 1 and 3 in1, Monoblock and Trio block model, Also semi automatic model for cap sealing, cup

AUTOMATIC METAL (ROPP) CAP SEALING MACHINE (MODEL: CPACS - M)

TECHNICAL SPECIFICATIONS:



MODEL NO.





CPACS-1 M





CPACS-4 M





CPACS-6 M





Direction





Left To Right.





Left To Right.





Left To Right.





Production Rate OF 100 ml containers





Up to 30 To 60 Bottles / Min





Up to 60 To 80 Bottles / Min





Up to 80 To 120 Bottles / Min





Electrical Supply





1.00 HP For

Main Drive





1.5 HP For

Main Drive





2.00 HP For

Main Drive





No of Sealing Head





Single





Four





Six





Power Requirement





440 Volts, 3 Phase (4 wire System) 50 Hz.





440 Volts, 3 Phase (4 wire System) 50 Hz.





440 Volts, 3 Phase (4 wire System) 50 Hz.





Height of Conveyor





Adjustable from 800 To 850 MM





Adjustable from 800 To 850 MM





Adjustable from 800 To 850 MM





Conveyor Width X Length





(Bigger width for larger size jars also available)





90mm  x 6 Ft.





90 mm X 6 Ft.





90 mm X 8 Ft.





Bottle Diameter





22 MM To 100 MM MAX. Adjustable as per client requirement





22 MM To 100 MM MAX. Adjustable as per client requirement





22 MM To 100 MM MAX. Adjustable as per client requirement





Height





55 MM To 210 MM MAX. Adjustable as per client requirement





55 MM To 210 MM MAX. Adjustable as per client requirement





55 MM To 210 MM MAX. Adjustable as per client requirement





ROPP cap





18 & 28 MM DIAMETER.(with help of change parts)





18 & 28 MM DIAMETER.(with help of change parts)





18 & 28 MM DIAMETER.(with help of change parts)
